Heavy duty Transfer Trolleyis a tool that runs on tracks and is specially used to move heavy goods along fixed routes in workshops. It can effectively improve factory production efficiency, reduce operating costs, and achieve accurate, fast, and efficient cargo transportation.
Whether transporting heavy equipment, raw materials, or semi-finished products, the heavy duty Transfer Trolley can move safely and effectively to ensure the smooth progress of production work.
Structure of Heavy Duty Transfer Trolley
Wheels :Cast steel wheels, made in-house by PEISA. They undergo quenching and bluing treatment for excellent wear resistance and high load-bearing capacity. Manufactured to the same standards as crane wheels.
Frame:Constructed with a platform and main frame. The structure is highly load-resistant, with no risk of deformation or breakage under normal working conditions.
Motor & Gearbox:Equipped with reputable domestic brand motors and gearboxes, used as a matched set for stable and reliable performance.
Battery:The battery is housed in a dedicated battery box located in the center of the trolley. It comes with a protective cover for easy replacement and daily maintenance.
Electrical Control Box:Usually mounted at the front or rear of the trolley. It contains all electrical components and control systems, serving as the core control unit of the entire transfer cart.
drawing of rail transfer cart
The DPX series heavy duty Transfer Trolley stands out for its exceptional load-bearing capacity.It can safely handle loads ranging from 1 ton up to 1,000 tons without any structural deformation.
It also offers excellent durability. According to our statistics over the past few years, the service life of DPX series products is no less than 10 years.
| Model | DPX | |||||||
| Rated load (T) | 5 | 10 | 20 | 30 | 50 | 60 | 150 | |
| Impacted rated load(T) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | |
| Structure of frame | Steel plates welded,beam structure | |||||||
| Table Size (mm) | Customized | |||||||
| Height (mm) | 450 | 530 | 600 | 700 | 800 | 800 | 1000 | |
| Motor Power (Kw) | 2 | 2 | 3 | 4 | 6 | 8 | 22 | |
| Rail Distance(mm) | 1430 | 2000 | ||||||
| Running speed(m/min) | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | |
| Battery Capacity(Ah) | 180 | 200 | 200 | 260-300 | 300-600 | |||
| Break method | electromagnetic brake | |||||||
| Ground clearance | 50-200 | |||||||
| Balance adjustment | mechanical conditioning | |||||||
| Operating Mode | Wireless remote control/car handle | |||||||
| Battery Type | Lead-acid battery, maintenance-free battery, lithium battery | |||||||
| Safety protectio | Infrared contact stop, fan-scanning radar | |||||||
| Mesa requirement | Laying rubber, V-shaped frame, table lifting, rollover, work frame | |||||||
Get Your Custom Solution?
1. Define Your Equipment Requirements
2. Submit your requirements via the "Contact Us" section
Provide the PEISA team with your detailed specifications: load capacity, dimensions, power supply method, color, voltage, special design features, etc.
3. The PEISA Team Develops a Technical Proposal and Quotation
4. Drawing Confirmation
5. Design Optimization: Tailored to Your Specific Needs
6. Order Placement
7. Production
Power Supply Mode:
| Power Supply Mode | Description |
|---|---|
| Battery power supply | DPX TYPE-Battery powered transfer carts are very flexible. They are ideal for environments requiring flexible movement, as they can move freely anywhere without being restricted by a power supply. |
| Low voltage track power supply | DDG TYPE-Suitable for fixed routes and large-scale cargo transfer. Enables fast movement along the track with high efficiency and no downtime. Ideal for long-distance and high-frequency work. |
| Cable drum power supply | DPJ TYPE-A common power supply method where power is drawn through a cable drum. Suitable for occasions requiring rapid goods transportation. |
| Cable line power supply | DPJ TYPE-Suitable for sites with pre-laid cables. Provides stable power input, making it appropriate for long-term and high-frequency transportation. |
In today's highly competitive market environment, factories must continuously improve production efficiency and reduce costs to achieve higher competitiveness. As a modern means of transportation, heavy duty Transfer Trolleys provide factories with new solutions, making production processes more intelligent and automated, and creating greater value for enterprises.
