Steel Coil Cart is a handling device specially designed for transporting cylindrical materials such as steel coils, aluminum coils, copper coils and wire coils. What distinguishes it from other product series is its tabletop design. Instead of a flat surface, it is equipped with a specially designed U-shaped groove or V-shaped bracket to secure the coils, preventing the materials from rolling or falling randomly and ensuring personnel safety.
This product is available in the DWP series or DPX series, meaning it can operate either on the ground or on a rail system (one of the two options is selectable). This design makes it suitable for 90% of factory environments.
Customizable Attributes of Steel Coil Transfer Cart
Load Capacity: 1–300 tons (customized based on coil weight and handling requirements)
Platform Size: Fully customized according to steel coil diameter, width, and workshop space
Power Supply System:Battery powered (lead-acid battery / lithium battery)/Cable reel powered/Low-voltage rail powered/Busbar power supply
Operation Type:Rail-mounted transfer cart/Trackless transfer cart (rubber wheels / polyurethane wheels)
Steering System (Trackless Type):Differential steering/Hydraulic steering/360° omnidirectional movement (optional)
Control System:Wireless remote control/Wired pendant control/PLC automatic control system/Semi-automatic / fully automatic operation
Speed Control:Fixed speed/Variable frequency speed control (VFD)
Driving Motor: AC motor / DC motor / servo motor (depending on application)
Wheel Type:Polyurethane wheels (indoor factory use)/Rubber wheels /Steel wheels (rail-mounted type)
Coil Support Structure:V-shaped cradle (standard design for steel coils)/U-shaped frame/Adjustable coil saddles/Anti-slip rubber pads/Hydraulic clamping device (optional)
Safety Systems:Emergency stop button/Sound and light alarm/Anti-collision sensors (infrared / laser)/Overload protection system/Automatic braking system
Optional Functions:Hydraulic lifting platform (up/down movement)/Weighing system (load monitoring)/Automatic docking system/Anti-roll coil locking device
Working Environment:Steel coil warehouse/Steel processing plant/Cold/hot rolling workshop/Outdoor yard (optional reinforced design)
After-Sales Service:
12-month warranty with spare parts support and technical assistance
Customer Background and Core Requirements
The customer is a professional pressure vessel manufacturer specializing in the production, storage, and transportation of various pressure vessels. Their key requirement was to efficiently transport pressure vessels between the workshop and the warehouse.
However, the transportation route included a special narrow passage, only 2.5 meters wide and 3.5 meters high, with steel plate protrusions along the floor. This severely restricted traditional handling methods and made transportation difficult, unsafe, and inefficient.
The customer clearly specified that:
The Steel Coil Cart height must not exceed 850 mm
The load capacity must reach 20 tons
Even the largest-diameter pressure vessels must pass smoothly through the narrow passage
The cart must safely handle floor protrusions without damaging the equipment or the ground
Parts
| Model | DWP | |||||||
| Rated load (T) | 5 | 10 | 20 | 30 | 50 | 60 | 150 | |
| Impacted rated load(T) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | |
| Structure of frame | Steel plates welded,beam structure | |||||||
| Table Size (mm) | Customized | |||||||
| Height (mm) | 450 | 530 | 600 | 600 | 600 | 700 | 700 | |
| Motor Power (Kw) | 3 | 4 | 5 | 9 | 12 | 15 | 40 | |
| Wheel Diameter(mm) | Φ300 | Φ350 | Φ400 | Φ400 | Φ600 | Φ700 | Φ900 | |
| Running speed(m/min) | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | 0-25 | |
| Break method | electromagnetic brake | |||||||
| Ground clearance | 50-100 | |||||||
| Balance adjustment | mechanical conditioning | |||||||
| Operating Mode | Wireless remote control/car handle | |||||||
| Battery Type | Lead-acid battery, maintenance-free battery, lithium battery | |||||||
| Safety protection | Infrared contact stop, fan-scanning radar | |||||||
| Surface requirement | Laying rubber, V-shaped frame, table lifting, rollover, work frame | |||||||
Customized Design and Technical Solutions
After fully understanding the customer's needs, we quickly formed a dedicated engineering team and focused on overcoming two key challenges: adapting to the narrow passage and handling steel plate protrusions.
1. Optimized Dimensions for Narrow Passages
Through repeated calculations and simulations, we finalized the cart dimensions at 3.5 × 2.2 × 0.75 meters.
The 750 mm height is well below the customer's 850 mm limit
The 2.2 m width fits comfortably within the 2.5 m passage
This ensures smooth passage even for the largest pressure vessels, without the need for route modification or manual adjustments.
2. Specialized Wheels for Floor Protrusions
To handle steel plate protrusions, we abandoned conventional wheels and adopted solid rubber wheels. These wheels provide excellent cushioning and wear resistance, allowing the cart to pass smoothly over uneven surfaces without jamming, excessive vibration, or damage to the floor.
To further enhance safety and durability:
The rated load capacity was increased to 22 tons, allowing the cart to easily absorb impact forces
The platform structure was reinforced to ensure stable support for various pressure vessels during transfer
Project Execution and Results
Throughout the project, we maintained close communication with the customer, continuously optimizing details based on on-site feedback. The equipment was successfully manufactured, delivered, and commissioned.
The Steel Coil Cart is now operating stably at the customer's facility, effectively solving the long-standing problems of narrow passages and floor protrusions. The customer has highly praised the equipment for its practicality, stability, and reliability.
